Name: Huawei V175 FTTR ONT | XGPON WiFi 6 Solution, Wholesale Price | Fast Delivery
Brand: Huawei
SKU: 2150085647-150085648
Availability: InStock

Description

Huawei V175 ONT is a high-performance optical network terminal designed for FTTR applications,with EU power adapter&English version. It supports XG-PON/10G-EPON adaptive technology and integrates Wi-Fi 6 for fast, stable, and wide-area wireless connectivity.The device features 4× Gigabit Ethernet ports, 1× POTS port for voice services, and 1× USB 2.0 port. With dual-band Wi-Fi 6 (2.4GHz & 5GHz) and 2×2 MIMO, it ensures strong signal coverage, low latency, and efficient performance.Ideal for residential and small business use, the Huawei V175 ONT delivers reliable high-speed internet for streaming, gaming, and smart home networks.The optional customization specification for this product is WiFi 7.

Device Parameters – Huawei V175

Dimensions (H x W x D)	157 mm x 250 mm x 30 mm (excluding the base)
Weight (without power adapter)	About 600 g (excluding the base)
System power supply	12 V DC, 2 A
Maximum power consumption	24 W
Installation mode	Vertically placed on a desk
NNI	XGPON / Asymmetric 10G-EPON auto-negotiation
Memory	256 MB Flash, 512 MB RAM
UNI	4xGE + 1xPOTS + 1xUSB 2.0 + 2.4GHz & 5GHz Wi-Fi + 1x optical port
Operating temperature	0°C ~ +40°C
Optical connector	NNI: SC/UPC UNI: SC/UPC
Operating humidity	5%–95% RH, non-condensing
Indicator	Indicators on front panel Indicators on rear panel: PON/LOS/TEL/USB/WLAN/WPS/FTTR/LAN port indicator
Power adapter input	100 V to 240 V AC, 50/60 Hz

Interface Parameters – Huawei V175

XGPON / 10G-EPON	XGPON: Class N1/N2a/E1 \| 10G-EPON: Class PRX30 Receiver sensitivity: XGPON: -27 dBm ; 10G-EPON: -28.5 dBm Overload optical power: XGPON: -8 dBm ; 10G-EPON: -9 dBm Wavelengths: XGPON (US 1260 nm, DS 1577 nm) ; 10G-EPON (US 1310 nm, DS 1577 nm) Wavelength blocking filter (WBF) Flexible mapping between GEM ports and T-CONTs SN/Password/SN+Password/Bi-directional authentication based on OMCI (XG-PON) MAC/Key/LOID (Asymmetric 10G-EPON) Forward error correction (FEC) in upstream & downstream SR and NSR DBA Upstream/downstream rate: XGPON (2.488 Gbit/s upstream, 9.953 Gbit/s downstream) 10G-EPON (1.25 Gbit/s upstream, 10.3125 Gbit/s downstream)
Wi-Fi (IEEE 802.11ax/ac/n/g/b/a)	IEEE 802.11 b/g/n/ax (2.4GHz) IEEE 802.11 a/n/ac/ax (5GHz) 2×2 MIMO (2.4GHz & 5GHz) WMM (Wi-Fi Multi Media) Multiple SSIDs WPS support Air interface rate: 574 Mbps (2.4GHz), 2402 Mbps (5GHz)
Ethernet port	Ethernet port-based VLAN tags and tag removal 1:1 VLAN, N:1 VLAN, or VLAN transparent transmission QinQ VLAN Limitation on the number of learned MAC addresses MAC address learning Supporting 10/100/1000 Mbit/s auto-adaptation
POTS port	Maximum REN: 4 G.711A/μ, G.729a/b, and G.722 encoding/decoding T.30/T.38/G.711 fax mode DTMF Emergency calls (with the SIP protocol)
Downstream optical port	P2MP optical port Theoretic upstream rate: about 1.25 Gbit/s; downstream: about 2.5 Gbit/s Plug-and-play of the Slave FTTR
USB port	USB 2.0

Product Functions & Features-Huawei V175

Smart interconnection	Smart Wi-Fi coverage SIP/H.248 auto-negotiation Any port any service Parental control
Smart O&M	IPTV video quality diagnosis Rogue ONT detection and isolation from the OLT WLAN simulation PPPoE/DHCP simulation testing
Multicast	IGMP v2/v3 snooping IGMP v2/v3 proxy MLD v1/v2 snooping
Layer 3 features	PPPoE/Static IP/DHCP NAT/NAPT Port forwarding ALG, UPnP DDNS/DNS server/DNS client IPv6/IPv4 dual stack, DS-Lite and IPv6 SPI Static/Default routes Multiple services on one WAN port
Security	SPI firewall Anti-DOS attack Filtering based on MAC/IP/URL addresses
Common O&M	OMCI/Web UI/TR069 Variable-length OMCI messages Dual-system software backup and rollback
QoS	Ethernet port rate limitation 802.1p priority SP/WRR/SP+WRR Broadcast packet rate limitation
Power saving	Indicator power saving TWT energy saving
Home network management	Fiber to the room, implementing all-optical home networking C-WAN architecture, centrally controlling and coordinating network-wide Wi-Fi resources by the Master FTTR Home Wi-Fi slicing and ONT cross-network acceleration assurance Intelligent Wi-Fi optimization for a home network Seamless Wi-Fi roaming within a home network (SRCN roaming technology, compatible with 802.11k/802.11v)

Huawei V173 ONT

Huawei OptiXstar V173 Front side

OptiXstar V152 Front side — OptiXstar V152 is This product PRO

Learn more about Optical Network Terminals (ONT) and XG-PON technology.

Additional information

NNI	XG-PON, 10G-EPON
UNI	4GE+1xPOTS+11ax 22 11AX 2.4GHz&5GHz Wi-Fi 6
Dimensions (H x W x D)	157 mm x 250 mm x 30 mm (excluding the base)
Weight（Without packaging box	About 600 g (excluding the base)
Optical connector	NNI: SC/UPC
System power supply	12 V DC, 1.5 A EU
Power adapter input	100 V to 240 V AC, 50/60 Hz
Wi-Fi	WIFI 6 2402Mhz, WIFI 7 2882Mhz
Product Condition	Brand new, Remanufactured
