Huawei HN8010Ts-20 10G-EPON
Price range: $240.00 through $260.00
Huawei HN8010Ts-20 | 10G-EPON 1*10GE, bridging-type ONT.
Description
The Huawei HN8010Ts-20 is an 10G-EPON bridging-type ONT in the Huawei all-optical access solution. It uses the 10G-EPON technology to implement ultra-broadband access for users.It with EU Standard Adapter，English Documents.
Device Parameters – Huawei HN8010Ts-20
| Dimensions (H x W x D) | 32 mm x 105 mm x 110 mm (without pads) |
|---|---|
| Weight | About 163 g |
| System power supply | 12 V DC, 1 A |
| Maximum power consumption | 6 W |
| Static power consumption | 5 W |
| Installation mode | – |
| NNI | 10G-EPON |
| Memory | 128MB Flash, 32MB RAM |
| UNI | 1*10GE |
| Operating temperature | 0°C to 40°C |
| Optical connector |
|
| Operating humidity | 5% RH to 95% RH (non-condensing) |
| Indicator | Power/PON/LOS/10G LAN |
| Power adapter input | 100-240 V AC, 50/60 Hz |
Interface Parameters
| 10G-EPON port |
|
|---|---|
| Ethernet port |
|
Product Functions & Features – Huawei HN8010Ts-20
| Smart O&M |
|
|---|---|
| Multicast |
|
| QoS |
|
| Security |
|
| Power saving |
|
Huaweir V173-50 combo Wifi6 7Db
OptiXstar V271-20 is This product Basic
This device supports advanced FTTH solutions based on GPON technology. Learn more about Optical Network Terminals.
* Specifications are based on the Huawei EN8010Ts-20 datasheet. Actual performance may vary depending on network conditions. Supports XGS-PON symmetrical 10G, providing high-speed data transmission, stable connectivity, and reliable performance for FTTH broadband and fiber access solutions.
Additional information
| NNI | 10G-EPON, 10G-EPON-S |
|---|---|
| UNI | 1*10GE |
| Dimensions (H x W x D) | 32 mm x 105 mm x 110 mm |
| Weight | About 163 g |
| Optical connector | NNI: SC/APC |
| System power supply | 12 V DC, 1 A |
| Power adapter input | 100 V to 240 V AC, 50/60 Hz |
Video
Video
FW Screenshot
FW Screenshot
