Huawei P812E
Price range: $350.00 through $400.00
Huawei P812E | XGS-PON (SFP+ Optical Module) | 4*GE + 1*2.5GE（Both the GE and 2.5GE ports support PoE/PoE+.）
Description
Huawei P812E is an ONU designed for scenarios such as enterprise campus and video backhaul. It provides 4*GE ports and 1*2.5GE port to provide high-quality voice, data, and HD video services.It with EU Standard Adapter，English Documents.
The Huawei OptiXstar P812E is a high-performance XGS-PON Optical Network Unit (ONU) designed for enterprise and advanced home networking environments. It delivers symmetrical 10Gbps fiber connectivity via an SFP+ optical module, ensuring ultra-fast and reliable data transmission.It supports symmetrical 10Gbps transmission via an SFP+ optical module and offers flexible deployment with optional GPON, XG-PON, and 10GEPON modules. Convert to the upstream line of the corresponding module, ensuring ultra-fast and reliable data transmission.
Product Highlights – Huawei P812E
- 802.1x and IPv6/IPv4 firewalls ensure device access security and network security.
- Supports XGS-PON uplink, 2.5G high bandwidth access.
- The PoE/PoE+ function supports flexible power supply.
- Features high reliability,type B dual-homing service protection.
Device Parameters – Huawei P812E ONT
| Dimensions (H x W x D) | 220 mm x 150 mm x 35 mm (Without floor mat) |
|---|---|
| Weight | About 1030 g |
| System power supply | 56 V DC, 1.42 A |
| NNI | XGS-PON |
| UNI | 4 × GE + 1 × 2.5 GE NOTE: Both GE and 2.5GE ports support PoE/PoE+ |
| Operating temperature | -5°C to +45°C |
| Static powerconsum ption |
|
| Maximum power consumption | 12 W (POE port without PD) 78 W (POE port with PD having the maximum power consumption) |
| Maximum PoE output power | Gross power 60W (up to 30W for one GE port) |
| Surge protection specifications | GE/2.5GE: common mode 4 kV; differential mode 0.5 kV. AC power: common mode 6 kV; differential mode 6 kV |
| Installation mode | Support indoor desktop installation, wall mounting, or network box installation. |
Interface Parameters
| SFP |
|
|---|---|
| GE/2.5GE |
|
Product Functions & Features – Huawei P812E ONT
| Automatic Service Provisioning |
|
|---|---|
| Smart O&M |
|
| Multicast |
|
| Layer 3 features |
|
| Security |
|
| QoS |
|
| Layer 2 Management |
|
| MTU & Jumbo Frame |
|
| Common O&M |
|
OptiXstar V271-20 is This product FTTR
This device supports advanced FTTH solutions based on GPON technology. Learn more about Optical Network Terminals.
* Specifications are based on the Huawei P812E datasheet. Actual performance may vary depending on network conditions. Supports XGS-PON symmetrical 10G,providing high-speed data transmission, stable connectivity, and reliable performance for FTTH broadband and fiber access solutions.
Additional information
| NNI | GPON, XGPON, 10GEPON, XGS-PON |
|---|---|
| UNI | 4*GE + 1*2.5GE Both the GE and 2.5GE ports support PoE/PoE+. |
| Dimensions (H x W x D) | 220mm x 150mm x 35mm(Without floor mat) |
| Weight | < 1030 g |
| Optical connector | NNI: SC （SFP+ Optical Module） |
| System power supply | 56V DC,1.42A |
| Power adapter input | 100 V to 240 V AC, 50/60 Hz |
Video
Video
FW Screenshot
FW Screenshot
