Huawei M990
$2,800.00
Huawei M990 | 1 × 50GPON(BOB) | 2 × 25GE/XGE/GE +2 × XGE/GE + 2*GE +2 × Clock interfaces with EU power adapter&English version.
Description
Huawei M990 is an 50G-PON ONU designed for scenarios such as enterprise campus and video backhaul. It supports 50GPON upstream and multiple access methods such as 25GE/XGE/GE downstream, achieving high-bandwidth access.It with EU Standard Adapter，English Documents.
The Huawei OptiXstar M990 is a high-performance 50G-PON Optical Network Unit (ONU) designed for enterprise and advanced home networking environments. It delivers 2 × 25GE/XGE/GE (optical) + 2 × XGE/GE (optical/electrical) + 2 × GE (electrical) + 2 × Clock interfaces, ensuring ultra-fast and reliable data transmission.It supports symmetrical 50Gbps transmission via an SFP+ optical module and offers flexible deployment with optional 50G-PON, XGS-PON, and 10G-EPON-S modules. Convert to the upstream line of the corresponding module, ensuring ultra-fast and reliable data transmission.
Product Highlights – Huawei M990
- 802.1x and IPv6/IPv4 firewalls ensure device access security and network security.
- Supports 50G-PON uplink, 49.7664G high bandwidth access
Device Parameters – Huawei M990
| Dimensions (H x W x D) | 320 mm × 220 mm × 43.6 mm (Without floor mat) |
|---|---|
| Weight | About 2.54Kg |
| System power supply | DC: 2 × DC, -48 V~-60 V; 1.0A |
| NNI | 1 × 50GPON(BOB) |
| UNI | 2 × 25GE/XGE/GE +2 × XGE/GE + 2*GE |
| Operating temperature | -40°C ~ +55°C |
| Static powerconsum ption |
|
| Maximum power consumption |
|
| Surge protection specifications | GE: common mode 4 kV; differential mode 1.5 kV. AC power: common mode 6 kV; differential mode 6 kV |
| Installation mode | Support Wall-mounted, 19-inch cabinet, network box. |
Interface Parameters
| Optical |
|
|---|---|
| GE1-GE2 |
|
| XGE3-XGE4 Port |
|
| 25GE/XGE 5-25GE/XGE 6 Port |
|
Product Functions & Features – Huawei M990
| Automatic Service Provisioning |
|
|---|---|
| Smart O&M |
|
| Multicast |
|
| Layer 3 features |
|
| Security |
|
| QoS |
|
| Layer 2 Management |
|
| MTU & Jumbo Frame |
|
| Common O&M |
|
OptiXstar V271-20 is This product FTTR
This device supports advanced FTTH solutions based on GPON technology. Learn more about Optical Network Terminals.
* Specifications are based on the Huawei P812E datasheet. Actual performance may vary depending on network conditions. Supports XGS-PON symmetrical 10G,providing high-speed data transmission, stable connectivity, and reliable performance for FTTH broadband and fiber access solutions.
Additional information
| NNI | XGS-PON, 50G-PON |
|---|---|
| UNI | 1 × 50GPON(BOB), 2 × 25GE/XGE/GE +2 × XGE/GE + 2*GE |
| Dimensions (H x W x D) | 320 mm × 220 mm × 43.6 mm(Without floor mat) |
| Weight | < 2.54Kg |
| Optical connector | NNI: SC |
| System power supply | DC: 2 × DC, -48 V~-60 V; 1.0A |
| Power adapter input | AC: 100 ～ 240V AC, 50/60Hz; 0.8A |
