Huawei V591E
Price range: $900.00 through $950.00
Huawei V591E | 50G-PON | 1x10GE+3xGE+1xPOTS+1xUSB3.0*+1x Down pon SC（XGS-PON）+2.4G&5G&5G WIFI 7 It is equipped with an EU standard adapter,English Documents.
Description
Huawei V591E is an 50G-PON ONU designed for scenarios such as enterprise campus and video backhaul. It provides 1*10GE ports and 3*GE port to provide high-quality voice, data, and HD video services.It is equipped with an EU standard adapter,English Documents.
The Huawei OptiXstar V591E is a high-performance 50G-PON Optical Network Unit (ONU) designed for enterprise and advanced home networking environments. It delivers asymmetric 50Gbps fiber connectivity via an optical port, ensuring ultra-fast and reliable data transmission.It supports asymmetric 50Gbps transmission via an optical port and offers flexible deployment with optional 50G-PON, XGS-PON. Convert to the upstream line of the corresponding module, ensuring ultra-fast and reliable data transmission.The new generation of Wi-Fi 7 technology provides a higher data rate and lower latency experience. The vertical arrangement structure utilizes the clearance height to free up floor space.
Product Highlights – Huawei V591E
- 802.1x and IPv6/IPv4 firewalls ensure device access security and network security.
- Supports 50G-PON uplink, 10G high bandwidth access.
- Features high reliability,type B dual-homing service protection.
Device Parameters – Huawei V591E
| Dimensions (H x W x D) | 197mm x 305mm x 42mm (Without floor mat) |
|---|---|
| Weight | About 1166 g |
| System power supply | 12V DC, 5 A |
| NNI | 50G-PON |
| UNI | 1x10GE+3xGE+1xPOTS+1xUSB3.0*+1x Down pon SC（XGS-PON）+2.4G&5G&5G WIFI 7 |
| Operating temperature | 0°C ~ +40°C |
| Static powerconsum ption |
|
| Maximum power consumption | 60W |
| Memory | 256 MB Flash，3 GB RAM |
| Surge protection specifications | GE: common mode 4 kV; differential mode 1.5 kV. AC power: common mode 6 kV; differential mode 6 kV |
| Installation mode | Support indoor desktop installation, wall mounting, or network box installation. |
Interface Parameters
| Optical |
|
|---|---|
| GE/10GE |
|
Product Functions & Features – Huawei V591E
| Automatic Service Provisioning |
|
|---|---|
| Smart O&M |
|
| Multicast |
|
| Layer 3 features |
|
| Security |
|
| QoS |
|
| Layer 2 Management |
|
| MTU & Jumbo Frame |
|
| Common O&M |
|
OptiXstar V271-20 is This product FTTR
This device supports advanced FTTH solutions based on GPON technology. Learn more about Optical Network Terminals.
* Specifications are based on the Huawei V591E datasheet. Actual performance may vary depending on network conditions. Supports XGS-PON symmetrical 10G,providing high-speed data transmission, stable connectivity, and reliable performance for FTTH broadband and fiber access solutions.
Additional information
| NNI | XGS-PON, 50G-PON |
|---|---|
| UNI | 1x10GE+3xGE+1xPOTS+1xUSB3.0*+1x Downstream optical port （XGS-PON）+2.4G&5G&5G 2882Mhz WIFI 7 |
| Dimensions (H x W x D) | 197mm x 305mm x 42mm(Without floor mat) |
| Weight | < 1166g |
| Optical connector | NNI: SC/UPC |
| System power supply | 12V DC, 5 A |
| Power adapter input | 100 ～ 240 V AC，50/60 Hz |
Video
Video
FW Screenshot
