Huawei HN8145X6N
$50.00
Huawei HN8145X6N XGPON/10G-EPON ONT 1×2.5GE+3xGE+1xPOTS+1xUSB2.0+ 2*2 11AX 2.4GHz&5GHz Wi-Fi 6 It is equipped with an EU standard adapter.&English version.
Description
Huawei HN8145X6N ONT is a high-performance optical network terminal designed for FTTH applications,It is equipped with an EU standard adapter&English version. It supports XGPON/10G-EPON adaptive technology and integrates Wi-Fi 6 for fast, stable, and wide-area wireless connectivity.The device features 1×2.5GE+3× Gigabit Ethernet ports, 1× POTS port for voice services, and 1× USB 2.0 port. With dual-band Wi-Fi 6 (2.4GHz & 5GHz) and 2×2 MIMO, it ensures strong signal coverage, low latency, and efficient performance.Ideal for residential and small business use, the Huawei HN8145X6N ONT delivers reliable high-speed internet for streaming, gaming, and smart home networks,hotel WiFi.
Device Parameters – Huawei HN8145X6N
| Dimensions (H x W x D) | 145mm x 210mm x 40mm (excluding the base) |
|---|---|
| Weight (without power adapter) | About 450 g (excluding the base) |
| System power supply | 12 V DC, 1.5 A |
| Maximum power consumption | 18 W |
| Installation mode | Vertically placed on a desk |
| NNI | XGPON / 10G-EPON auto-adaptive |
| Memory | 256 MB Flash, 512 MB RAM |
| UNI | 1×2.5GE+3xGE+1xPOTS+1xUSB2.0+2.4GHz&5GHz Wi-Fi+1xoptical port |
| Operating temperature | 0°C ~ +40°C |
| Optical connector |
|
| Operating humidity | 5%–95% RH, non-condensing |
| Indicator | Indicators on front panel Indicators on rear panel:ON/LOS/4-GE/3-GE/2-GE/1-2.5GE/USB/TEL/WLAN/WPS/FTTR |
| Power adapter input | 100 V to 240 V AC, 50/60 Hz |
Interface Parameters
| GPON / XG-PON |
|
|---|---|
| Wi-Fi (IEEE 802.11ax/ac/n/g/b/a) |
|
| Ethernet port |
|
| POTS port |
|
| Downstream optical port |
|
| USB port |
|
Product Functions & Features – Huawei HN8145X6N ONT
| Smart interconnection |
|
|---|---|
| Smart O&M |
|
| Multicast |
|
| Layer 3 features |
|
| Security |
|
| Common O&M |
|
| QoS |
|
| Power saving |
|
| Home network management |
|
| NCE cloud management |
|
Huaweir V173-50 combo Wifi6 7Db
This device supports advanced FTTH solutions based on GPON technology. Learn more about Optical Network Terminals.
* Specifications are based on the HN8145X6N datasheet. Actual performance may vary depending on network conditions. Supports XG-PON symmetrical 10G,providing high-speed data transmission, stable connectivity, and reliable performance for FTTH broadband and fiber access solutions.
Additional information
| NNI | XG-PON, 10G-EPON |
|---|---|
| UNI | 1×2.5GE+3xGE+1xPOTS+1xUSB2.0+ 2*2 11AX 2.4GHz&5GHz Wi-Fi 6 |
| Dimensions (H x W x D) | 145mm x 210mm x 40mm (excluding the base) |
| Weight（Without packaging box | About 600 g (excluding the base) |
| Optical connector | NNI: SC UNI: SC |
| System power supply | 12 V DC, 1.5 A |
| Power adapter input | 100 V to 240 V AC, 50/60 Hz |
| Wi-Fi | WIFI 6 2402Mhz |
